Antec C6 WOOD ATX Mid Tower Gaming Casing
Key Features
- Mainboard Support: ATX, Micro-ATX, ITX
- 4mm Tempered Glass, Bottom Dust Filter
- Pre-installed Fans: 3x 120mm Fans
- I/O Ports: 2 x USB 3.0, 1 x Type-C 3.2, Headphone/Mic Jack
Description
Antec C6 WOOD ATX Mid Tower Gaming Casing
The Antec C6 WOOD ATX Mid Tower Gaming Casing combines a modern chassis design with strong hardware support for gaming PC builds. Its black exterior uses steel, plastic, and glass for a clean appearance. A 4mm tempered glass side panel provides a clear view of internal components and lighting. The case supports ATX, Micro-ATX, and Mini-ITX motherboards for different gaming configurations. With seven expansion slots, it supports a wide range of graphics and add-on components. The chassis measures 455 x 235 x 485mm and weighs 8.8kg. It supports graphics cards up to 450mm long and CPU coolers up to 180mm high. The Antec C6 WOOD also supports multiple cooling configurations for demanding systems. Its top radiator support includes 120mm, 140mm, 240mm, 280mm, and 360mm options. A 120mm radiator can also be installed at the rear. Fan support includes three 120mm or two 140mm fans at the top. The rear supports one 120mm or 140mm fan. Pre-installed cooling includes two 120mm PWM reverse fans on the PSU shroud. It also includes one 140mm PWM rear fan for additional airflow. Front connectivity includes two USB 3.0 ports and one USB Type-C 3.2 Gen 2 port. The Type-C port supports data speeds up to 10Gbps. A combined headphone and microphone jack provides convenient audio connectivity. Storage support includes one 3.5-inch and one 2.5-inch drive bay. PSU support allows standard mounting up to 150mm and side mounting up to 160mm.
Specification
| Brand & Model | ||
| Brands | Antec | |
| Model | C6 WOOD | |
| Details | ||
| Case Type | Mid Tower | |
| Motherboard Support | ATX, M-ATX, ITX | |
| Materials | Steel + Plastic + Glass | |
| Side Panel | 4mm Tempered Glass | |
| Fan Support | Top: 3 x 120mm / 2 x 140mm Rear: 1 x 120mm / 1 x 140mm |
|
| Pre-installed Fans | 2 x 120mm PWM reverse fans on the PSU shroud 1 x 140mm PWM fan at the rear |
|
| Radiator Support | Top: 120 / 140 / 240 / 280 / 360mm Rear: 120mm |
|
| I/O Port | Power, USB 3.0 x 2, Type-C 3.2 Gen 2 x 1(10Gbps), Headphone/Mic Combo Jack | |
| Filter | bottom dust filter | |
| Expansion & Drive Bay | ||
| Expansion Slots | 7 | |
| Drive Bays | 3.5" : 1 2.5" : 1 |
|
| Physical Specification | ||
| Color | Black | |
| Dimensions | 455 x 235 x 485mm (DWH) | |
| Clearance Space | ||
| Max GPU Length | ≤ 450mm | |
| Max CPU Cooler Height | ≤ 180mm | |
| Max PSU Length | Standard mounting (excluding cables) ≤ 150mm (For modular PSUs, the PSU chamber fan bracket must be removed.) Side mounting (excluding cables) ≤ 160mm |
|
| Warranty Information | ||
| Warranty | No | |
