Gamdias HELIOS M1-600B 600W 80 Plus Bronze Power Supply

More about this Item

Gamdias HELIOS M1-600B 600W 80 Plus Bronze Power Supply

Gamdias HELIOS M1-600B 600W 80 Plus Bronze Power Supply

The Gamdias HELIOS M1-600B 600W 80 Plus Bronze Power Supply is a reliable and efficient ATX power solution designed to support modern PC builds with stable and consistent performance. Built on the ATX12V v2.4 standard, it delivers a total output of 600 watts while achieving up to 85% power efficiency, thanks to its 80 PLUS Bronze certification, which helps reduce power loss and heat generation. The PSU uses high-quality capacitors to ensure long-term durability and steady voltage output across all rails, including +3.3V, +5V, +12V, -12V, and +5Vsb, with a strong +12V rail rated at 49A, making it suitable for gaming PCs and mid-range workstations. It supports the C6/C7 power state for improved energy efficiency and operates within an AC input range of 180–240V, ideal for stable operation. Cooling is handled by a 120mm long-lifespan sleeve bearing fan with automatic fan speed optimization based on temperature, ensuring quiet and efficient thermal management. In terms of connectivity, the HELIOS M1-600B offers a 20+4 pin main power connector, 4+4 pin CPU connector, two 6+2 pin PCI-E connectors, four SATA connectors, and two Molex connectors, all using black flat, non-modular cables for easier cable management and improved airflow. Safety is further enhanced with comprehensive protection features, including OVP, UVP, OPP, SCP, and OCP, making the Gamdias HELIOS M1-600B a dependable and well-balanced power supply for everyday and gaming PC systems.
