Specification
| Brand & Model | ||
| Brands | MSI | |
| Model | MAG PANO M100R PZ | |
| Details | ||
| Case Type | Mid-Tower | |
| Motherboard Support | Support M-ATX(Back-connect supported) / ITX | |
| Side Panel | 270-degree panoramic tempered glass | |
| Fan Support | Top: 3 x 120 mm / 2 x 140 mm Rear: 1 x 120 mm / 1 x 140 mm Side: 3 x 120 mm Bottom: 1 x 120 mm PSU Shroud: 2 x 120 mm |
|
| Pre-installed Fans | Side: 3 x ARGB Fan (Reverse-blade) Rear: 1 x ARGB Fan |
|
| Radiator Support | Top: 120 / 240 / 360 mm Rear: 120 / 140 mm |
|
| I/O Port | 1 x USB 3.2 Gen 1 Type-A 1 x USB 3.2 Gen 2x2 Type-C 1 x Audio-Out / Mic-in 1 x LED Switch Button 1 x Power Button |
|
| Expansion & Drive Bay | ||
| Expansion Slots | 5 | |
| Drive Bays | 1 x 2.5” 1 x 2.5”/3.5” combo (up to 2 x 2.5” or 1 x 2.5”+ 1 x 3.5”) |
|
| Physical Specification | ||
| Color | White | |
| Dimensions | 440 x 235 x 405 mm / 17.32 x 9.25 x 15.94 inches | |
| Weight | 8.66 kg | |
| Clearance Space | ||
| Max GPU Length | 390 mm / 15.35 inches *Support horizontal installation only |
|
| Max CPU Cooler Height | 175 mm / 6.9 inches | |
| Max PSU Length | 200 mm / 7.87 inches | |
| Warranty Information | ||
| Warranty | No warranty | |
