MSI SPATIUM M470 Pro PCIe 4.0 NVMe M.2 500GB SSD
Key Features
- Storage Capacity: 500GB
- Interface: PCIe Gen4 x4, NVMe 1.4
- Sequential Read: Up to 5500MB/sec
- Sequential Write: Up to 3600MB/sec
Description
MSI SPATIUM M470 Pro PCIe 4.0 NVMe M.2 500GB SSD
The MSI SPATIUM M470 Pro PCIe 4.0 NVMe M.2 500GB SSD provides 500GB of storage with a PCIe Gen4 x4 interface and NVMe 1.4 support. It delivers sequential read speeds of up to 5500MB/s and sequential write speeds of up to 3600MB/s. This MSI M470 Pro 500GB SSD uses 3D NAND flash memory and an M.2 2280 form factor, with compatibility for PCIe Gen4, Gen3, Gen2, and Gen1 systems. It supports random 4KB read speeds of up to 500,000 IOPS and random write speeds of up to 900,000 IOPS. The MSI Gen4 NVMe SSD has a maximum operating power of 4.3W and supports TRIM, SMART, LDPC ECC, End-to-End Data Path Protection, APST, and Pyrite encryption for data security. Measuring 80 × 22 × 2.15mm, this MSI 500GB NVMe SSD is designed for compatible desktop and laptop systems requiring PCIe 4.0 storage performance.
Specification
| Brand & Model | ||
| Brand | MSI | |
| Model | SPATIUM M470 Pro | |
| Details | ||
| Capacity | 500GB | |
| Interface | PCIe Gen4 x4, NVMe 1.4 | |
| Form Factor | M.2 2280 | |
| Others | Compatibility: PCIe Gen5 / Gen4 / Gen3 / Gen2 / Gen1 DRAM Cache: 2GB LPDDR4 Flash Memory: 3D NAND Controller: PHISON E27T / PHISON E33 Real-Time SSD System Stability Monitoring |
|
| Performance | ||
| Max Sequential Read | Up to 5500 (MB/s) | |
| Max Sequential Write | Up to 3600 (MB/s) | |
| Temperature | ||
| Power Consumption | 4.3W | |
| Operating Temperature | 0°C – 70°C | |
| Storage Temperature | -40°C – 85°C | |
| Dimensions & Weight | ||
| Height | 2.15mm | |
| Width | 22.00mm | |
| Warranty | ||
| Warranty | 5 Years | |
