Specification
| Brand & Model | ||
| Brands | Gamdias | |
| Model | ATLAS M4 |
|
| Details | ||
| Case Type | MID Tower |
|
| Motherboard Support | ATX、Micro-ATX、Mini-ITX |
|
| Materials | SPCC & ABS & Tempered glass | |
| Fan Support | Top: 3 x 120mm Rear: 1 x 120mm / 1 x 140mm Bottom: 3 x 120mm |
|
| Pre-installed Fans | Rear: 1 x 120mm PWM ARGB Fan Bottom: 3 x 120mm PWM ARGB Fans |
|
| Radiator Support | Top: 360mm / Rear: 120mm | |
| I/O Port | Type-C x 1, USB 3.0 x2, HD Audio x1, LED Control x1 | |
| Others | CASE Color: Black |
|
| Expansion & Drive Bay | ||
| Expansion Slots | 7 | |
| Drive Bays | 1 x 3.5 + 1 x 2.5 or 2 x 2.5 | |
| Physical Specification | ||
| Color | Black | |
| Dimensions | 430 x 235 x 434mm | |
| Clearance Space | ||
| Max GPU Length | 425mm | |
| Max CPU Cooler Height | 175mm | |
| Max PSU Length | 160mm | |
| Warranty Information | ||
| Warranty | No | |
